1/10 GRANITE 4WD V3 MEGA 550 Brushed Monster Truck RTR, Blue

4.3 out of 5 Customer Rating
ARRMA #ARA4202V3T1
Regional Variations : ARA4202V3I
Earn points on this item
In Stock
Selected Store
color:

| Checkout out our products at a store near you.
Product Logo
Blast through even brutal terrain with the full-time 4WD traction and power of the 1/10 scale ARRMA GRANITE 4X4 MEGA 550 Brushed RTR. The muscular design of this RC monster truck 4x4 amplifies your driving thrills as only ARRMA can. Unleash astonishing speed capabilities of 30 mph or more with the included NiMH battery and optional gearing. Upgrade to 2S LiPo power and take the speed, run time, and monster truck remote control madness to a whole new level. This ARRMA RC truck arrives fully assembled and ready-to-run. Just add AA transmitter batteries and send it!
  • MEGA 12T brushed 550 motor
  • MEGA waterproof ESC
  • IC3™ connectors (EC3™) compatible
  • 30MPH (48km/h) speed achievable in optimum driving conditions with optional gearing
  • Ready to Run (RTR) comes fully assembled with everything needed besides AA batteries!
  • (1) ARRMA® GRANITE™ 4X4 MEGA 550 1/10 Scale 4WD Electric Monster Truck RTR
  • (1) MEGA Waterproof* ESC
  • (1) MEGA 12T Brushed 550 Motor
  • (1) Spektrum™ Waterproof* SPMS650 Digital Servo
  • (1) Spektrum™ SLR300 Receiver
  • (1) Spektrum™ 2.4GHz SLT3™ 3-Channel Transmitter
  • (1) Dynamite® 3300mAh 8.4V 7-Cell Speedpack® 2 Hump NiMH Battery
  • (1) ADC-N7 7-Cell NiMH Wall Charger
  • (1) 1/10 GRANITE 4WD V3 MEGA Manual
  • (4) AA batteries for Transmitter
1/10 GRANITE 4WD V3 MEGA 550 Brushed Monster Truck RTR, Blue

Features

  • Stronger chassis and retained hinge pin plates
  • Steering with more clearance for stones
  • Castellated slipper pad and sliding gear mesh
  • 23T Spline servo saver
  • Brushless-ready 37T 1.35Mod diffs with silicone O-rings
  • Power Module with sliding gear mesh and improved dirt management
  • Rubber shielded bearings throughout
  • Oil-filled shocks with silicone O-rings
  • New body design, front and rear bumpers, paint and decals
  • New vented tires
  • MEGA 12T brushed 550 motor
  • MEGA waterproof* ESC
    * Note: For details on waterproof standards, refer to the instruction manual
  • IC3™ connectors (EC3™) compatible
  • Signature easy-access modular design
    • Easy-access power module
    • Easy-access electronics module
    • Easy-access diff module removal front and rear
  • Double wishbone suspension front and rear
  • Metal-geared differentials
  • Adjustable ride height
  • Adjustable body mounts
  • Extended height dirt defenders
  • Multi-terrain dBoots® Fortress™ MT tires
  • Tough multi-spoke black MT wheels
  • ADC-N7 7-cell NiMH wall charger
  • 2-year limited warranty (see website for details)
  • 30MPH (48km/h) speed achievable in optimum driving conditions with optional gearing

Overview

Built for extreme all-terrain action, the 1/10 scale ARRMA GRANITE 4X4 MEGA 550 Brushed RTR amplifies the excitement of your monster truck RC bashing as only an ARRMA RC truck can. This RC monster truck 4x4 rides tall on massive, high-traction, multi-terrain tires. They turn the rugged powertrain’s 30+ mph speed potential into turf-pounding, fast RC truck fun almost anywhere you please. Go ahead and send it. From the full-time 4WD transmission to the large diff gears, every part of this big RC truck is built to survive brutal blasting. ARRMA also gives fast, easy maintenance a whole new meaning with the ingenious modular chassis design. You can reach almost any component by removing just a few screws. With the included Spektrum 3-channel radio, monster truck remote control is easy for anyone. New drivers can set the throttle limits at 50% or 75% until ready to use the full speed potential. The included, high capacity NiMH battery delivers enough performance and run time to make this the one of the best RC monster trucks for any skill level. You can also upgrade to 2S LiPo power and take your RC 4x4 off-road fun to the next level. Fully assembled and ready-to-run, the ARRMA GRANITE 4X4 MEGA 550 Brushed RTR needs nothing more than four AA batteries before it’s GO time!

Video Overview



Support Video Playlist



Spektrum™ 3-Channel SLT3™ 2.4GHz radio and SLR300 Waterproof* Receiver
Spektrum™ 3-Channel SLT3™ 2.4GHz radio and SLR300 Waterproof* Receiver

  • Fast response SLT™ protocol
  • Foam wheel
  • Improved grip and trigger feel
  • Improved wheel and trigger force
  • 2-way thumb switch third channel
  • 50% and 75% Throttle mode (for beginners)
  • Tactic® SLT™ receiver compatible



Dynamite 3300mAh 8.4V 7-Cell Speedpack 2 Hump NiMH Battery
Dynamite® 3300mAh 8.4V 7-Cell Speedpack® 2 Hump NiMH Battery

  • 35% more run time over the 2400mAh pack in the previous version
  • 7 cell NiMH Hump Pack
  • 3300mAh capacity
  • 8.4 Volts
  • Factory-fitted IC3® Connector (EC3 Compatible)



Spektrum SPMS650 digital servo
Spektrum™ SPMS650 digital servo

  • 84 oz-in (6 kg-cm) @ 6V
  • 20% more torque than the previous ADS-5 servo for improved steering feel
  • Waterproof*
* Note: For details on waterproof standards, refer to the instruction manual



Strengthened Chassis
Strengthened Chassis

Stronger chassis and retained hinge pin plates



Larger pull tab on power module
Larger pull tab on power module



Castellated slipper pad and sliding gear mesh
Castellated slipper pad and sliding gear mesh



Rubber shielded bearings
Rubber shielded bearings



Redesigned Steering
Redesigned Steering

Steering with more clearance for stones.



Tougher brushless ready transmission
Tougher brushless ready transmission

Metal input spline moulded into composite gear. Same gears as the ARRMA 4S.



Sealed Wheels & Vented Tires
Sealed Wheels & Vented Tires

Stops dirt getting in and allows water to escape.



Multi-terrain dBoots Fortress MT tires
Multi-terrain dBoots® Fortress™ MT tires

Tough, multi-spoke black MT wheels with dBoots® Fortress™ MT tires give the GRANITE™ 4X4 MEGA RTR effective traction for bashing on almost any terrain.



Silicone O-rings
Silicone O-rings

Oil-filled shocks with silicone O-rings



Heavy-Duty Bumpers
Heavy-Duty Bumpers

Impact absorbing.



Proven Power Package
Proven Power Package

  • MEGA 12T brushed 550 motor
  • MEGA waterproof* ESC
    * Note: For details on waterproof standards, refer to the instruction manual
  • IC3™ connectors (EC3™) compatible



Easy-access power module
Easy-access power module

  • Detaches from chassis as a complete unit by removing one screw.
  • Contains motor, motor plate, slipper clutch assembly and gear cover.



Easy-access electronics module
Easy-access electronics module

  • Two-piece molding screwed to the chassis contains a waterproof receiver box, servo mount, and ESC tray.
  • Receiver mounts inside sealed module for protection from dirt and moisture.
  • ESC screws to the top for easy maintenance and switch access.
  • Servo mounts on the side for quick servicing.



Metal-geared differentials
Metal-geared differentials

  • Large gears can withstand huge torque, and internal metal gears have been chosen for reliability during extreme bashing.
  • Easy-access front and rear diff module removal.



Proven tough composite shock towers
Proven tough composite shock towers



Product Specifications

Receiver
Included
Shock Type
Oil-Filled, Coil-Over Springs
Product Weight
6.69
Bushing Material
Metal
Charger
Included
Differential
2 Gear Diffs
Pinion
14T
Scale
1/10
Body
Painted, decalled and trimmed
Final Drive Ratio
18.5
Motor Type
Brushed
Rear Track
13.46 in (342mm)
Wheelbase
11.3 in (287mm)
Power Type
Electric
Gear Pitch
48-pitch
Servos
Included
Front Track
13.46 in (342mm)
Power System
MEGA
Product Width
13.46" (342 mm)
Radio
Included
Technology
SLT Protocol
Battery
Included
Connector Type
IC3, EC3
Ground Clearance
1.85 in (47mm)
Internal Gear Ratio
2.85
Product Length
17.76" (451 mm)
Spur Gear
91T
Steering Type
2WS
Suspension
Independent
Tire Tread
dBoots Fortress MT
Vehicle Type
Monster Truck
Water-Resistant
Yes
Ball Bearings
Transmission
Chassis
Molded Composite
Drivetrain
4WD
Product Height
8.11" (206 mm)
Top Speed
30+
Wheel Hex Size
14mm
Completion Level
Ready-To-Run
